    Product Details:

    Place of Origin: China
    Brand Name: IKP
    Model Number: IKP-PFC-5060-12

    Payment & Shipping Terms:

    Minimum Order Quantity: 200pcs
    Price: 5.35USD
    Packaging Details: Carton
    Delivery Time: 5-15 work days
    Payment Terms: L/C, T/T
    Supply Ability: 10,000pcs/week
    Contact Now
    Detailed Product Description

    Features & Application
    ▪ Separated windings for minimum interwinding capacitance
    ▪ Single layer windings for highest common mode impedance over the widest frequency range
    ▪ OR wound on nylon casing to protect windings
    ▪ Spacer provides 1-3mm creepage distance for UL, CSA, IEC compliance
    ▪ All materials used are UL94-VO recognized
    ▪ Operating temperature: -40ºC to +105ºC. Suitable for 50Hz to 500 KHz
    ▪ Available in either vertical or horizontal mount
    ▪ Application includes power line filtering, EMI/REI for switch mode power supplies
    ▪ Available in vertical header mount for ease in PCB assembly
    ▪ Easy FR-4 board mounting Good vibration resistance
    106uh 105A 3-Phase Power Factor Correction (PFC) Chokes for Energy Saving White Goods


    Electrical characteristics:
    Header Mounted Toroidal Common Mode Line Chokes

    Part NO.
    #TOD-L-I(A)
    Inductance Max. D.C.
    Resistance
    Current
    Rating
    Mounting Dimension(mm)
    Coil size code A×B×C
    #T310-280-13 0.280mH 2.9milli-ohm 13A Horizontal 38×38×19
    #T250-425-8 0.425mH 4.26milli-ohm 8A Vertical 32×30×21
    #T310-580-13 0.580mH 10milli-ohm 13A Vertical 38×38×18
    #T250-1000-8 1.000mH 0.02ohm 8A Vertical 30×28×13
    #T220-1000-3.2 1.000mH 15.3milli-ohm 3.2A Vertical 26×26×17
    #T220-1500-2 1.500mH 18.0milli-ohm 3.2A Vertical 26×26×18
    #T220-1800-5 1.800mH 0.05ohm 5A Horizontal 26×28×18
    #T220-2200-5 2.200mH 0.04ohm 5A Vertical 26×26×19
    #T250-3500-1.5 3.500mH 80.0milli-ohm 1.5A Horizontal 30×32×16
    #T250-3700-4 3.700mH 0.007ohm 4A Vertical 30×32×17
    #T310-7200-2.5 7.200mH 93.0milli-ohm 2.5A Horizontal 38×40×18
    #T310-11000-1.5 11.000mH 184.0milli-ohm 1.5A Vertical 40×40×19

    Low Profile, Small Size Common Mode Choke

    Part NO.
    #TOD-L-I(A)
    Inductance Max. D.C.
    Resistance
    DC Current
    Rating
    Mounting Dimension(mm)
    Coil size code A×B×C
    #T220-1180-7.5 1.180mH 12.5milli-ohms 7.5Amps Horizontal 26×28×20
    #T220-65-23.5 65.000μH 0.9milli-ohms 23.5Amps Vertical 26×26×18
    #T220-100-19 100.000μH 1.3 milli-ohms 19Amps Vertical 28×26×18
    #T220-180-15 180.000μH 2.5milli-ohms 15Amps Vertical 26×26×20
    #T220-470-12 470.000μH 4.0milli-ohms 12Amps Vertical 28×26×18
    #T220-880-9 880.000μH 6.5milli-ohms 9Amps Horizontal 28×30×20

    High Current Common Mode Line Chokes

    Part NO.
    #TOD-L-I(A)
    Inductance Max. D.C.
    Resistance
    Current
    Rating
    Mounting Dimension(mm)
    Coil size code A×B×C
    #T310-100-30 0.100mH 3.0milli-ohms 30Amps Horizontal 38×40×18
    #T310-100-30A 0.100mH 3.0milli-ohms 30Amps Vertical 36×36×15
    #T310-150-20 0.150mH 3.4milli-ohms 20Amops Horizontal 36×36×16
    #T310-150-20A 0.150mH 3.4milli-ohms 20Amops Vertical 38×38×18
    #T310-150-30 0.150mH 3.5milli-ohms 30Amps Vertical 38×38×19
    #T250-200-15 0.200mH 5milli-ohms 15Amps Horizontal 30×28×15
    #T310-200-18 0.200mH 5milli-ohms 18Amps Horizontal 36×36×16
    #T310-200-15A 0.200mH 5milli-ohms 15Amps Vertical 38×38×18
    #T250-200-18 0.200mH 5milli-ohms 18Amps Vertical 30×28×15
    #T250-300-15 0.300mH 7.3milli-ohms 15Amps Horizontal 30×32×18
    #T250-300-15A 0.300mH 7.3milli-ohms 15Amps Vertical 30×28×17
    #T250-600-9 0.600mH 10milli-ohms 9Amps Horizontal 30×30×18
    #T250-600-9 0.600mH 10milli-ohms 9Amps Vertical 30×28×19

    *We can design and manufacture customized part with specific requirement
