Name: Customized SMD Type Efd Core SMPS High Frequency Pulse Transformer
Brand: IKP Electronics Co., Ltd.
SKU: EFD Type
Price: 0.78 USD
Availability: InStock

Home Products CCFL Transformers

Customized SMD Type Efd Core SMPS High Frequency Pulse Transformer

Product Details:

Place of Origin:	CHINA
Brand Name:	IKP
Certification:	CE/UL/REACH/ROHS
Model Number:	EFD Type

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	0.78-0.88
Packaging Details:	Carton
Delivery Time:	10-15 days
Payment Terms:	L/C, T/T
Supply Ability:	100,000/week

Contact Now

Detailed Product Description

Basic Info.

Model NO.

EFD Type

Core

Core-type Transformer

Cooling Method

Dry-type Transformer

Winding Type

Multi-winding Transformer

Certification

ISO9001

Usage

Single-phase Transformer, Rectifier Transformer, Combined Transformer, Power Transformer, Distribution Transformer

Frequency Characteristics

High Frequency

Shape of Core

Efd

Brand

Ikp

Transport Package

Carton, Pallet

Specification

EFD Series

Trademark

ODM/OEM

Origin

China

HS Code

8504319000

Production Capacity

5000000PCS/Year

Product Description

Features:

1. Operating Frequency: 50~200KHz
2. Low-cost, all models mainly used in less demanding fields on the electromagnetic shielding power field.
3. Power frequency because of work, safety regulations and other requirements of the different temperature level will change.

Specifications (Unit: mm):

P/N.	PINS	Dimensions(mm)
P/N.	PINS	A	B	C+/-0.5	D	E	FIG
EFD-12	8	6	17	20	3	13.5	2
EFD-15	10	7.3	18.2	21.35	2.5	15	1
EFD-15	10	7.5	19.3	22.6	3	16.7	2
EFD-20	10	9.4	25.3	27.7	3.75	21.7	2
EFD-20	12	9.7	24	26.8	3	20	1
EFD-25	10	13.4	29.7	35.4	5	25	2
EFD-25	10	12.6	29.7	31.5	5	25	1
EFD-30	12	12.6	31.6	35.3	5	30	2

Electrical performance:

1. Operating frequency: 20kHz-500KHz
2. Output power: 30 to 2000 W
3. Operating temperature:-40 ºC to +125 ºC
4. Storage temperature:-25 ºC to +85 ºC

Applications:

Household appliances, switching power supplies, communications equipments, medical equipments, production equipments, CCTV, computers, lighting equipments.

Kindly Reminder:

1. About the SAMPLES. Please provide specific specifications or sample material, we will evaluate your products, design and produce samples.
2. About PRICE. Transformers are custom products, due to the different materials and design, even if the same model, the price is not the same. The price also depends on the complexity of the parameters and the amount of orders.
3. About SHIPPING. Samples in 3-5 days; mass production in 7-15 days.
4. About PAYMENT. Foreign customers:100% T / T; domestic customers: 30 days after delivery, according to the invoice payment.
5. Packaging, logistics, according to the specific requirements of the purchase and sale contracts.
6. Contact us now for more details:

Customized SMD Type Efd Core SMPS High Frequency Pulse Transformer
