Name: SMD Type Efd10/Efd15/Efd25/Efd40 High Frequency Transformers
Brand: IKP Electronics Co., Ltd.
SKU: IKP-LF-EFD Series
Price: 0.52 USD
Availability: InStock

Home Products High Frequency Transformers

SMD Type Efd10/Efd15/Efd25/Efd40 High Frequency Transformers

Product Details:

Place of Origin:	CHINA
Brand Name:	IKP
Certification:	CE/UL/REACH/ROHS
Model Number:	IKP-LF-EFD Series

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	US$0.52-0.55
Packaging Details:	Carton
Delivery Time:	10-15 days
Payment Terms:	L/C, T/T
Supply Ability:	100,000/week

Contact Now

Detailed Product Description

Basic Info.

Model NO.

IKP-LF-EFD Series

Core

Core-type Transformer

Cooling Method

Dry-type Transformer

Winding Type

Separated Winding Transformer

Certification

ISO9001-2000, ISO9001, CCC

Usage

Single-phase Transformer

Frequency Characteristics

High Frequency

Shape of Core

Efd

Brand

Ikp

Transport Package

Carton & Tray

Specification

EFD SERIES

Trademark

IKP-ELEC

Origin

Hefei, China

HS Code

85043190

Production Capacity

50000PCS/Week

Product Description

FEATURES:
1. Operating Frequency: 50~200KHz
2. Magnetic flux leakage small, high power density, suitable for flat design.
3. Power frequency because of work, safety regulations and other requirements of the different temperature level will change.

Physical and Electrical Performance Parameters

Type	Shape Structure	Dimension						Power range
Type	Shape Structure	A	B	C	D	E	F	Power range
EFD10	SMD	12.0Max	5.1±0.5	14.6±0.5	0.3±0.1	2.54±0.3	12.4±0.5	12W Max
EFD12		14.0Max	6.2±0.5	16.3±0.5	0.3±0.1	3.0±0.3	20.0±0.5	15W Max
EFD15		16.5Max	7.5±0.5	14.8±0.5	0.4±0.1	2.4±0.3	21.4±0.5	25W Max
EFD20		22.0Max	9.6±0.5	20.1±0.5	0.4±0.1	3.75±0.3	25.1±0.3	30W Max
EFD25		26.5Max	12.6±0.5	26.0±0.5	0.4±0.1	5.0±0.3	31.5±0.5	45W Max
EFD30		31.5Max	11.8±0.5	31.0±0.5	3.7±0.3	5.0±0.3	40.0±0.5	100W Max
EFD40		49.0Max	12.7±0.5	44.3±0.5	4.2±0.3	5.0±0.3	65.0±0.5	350W Max
EFD50		57.0Max	12.7±0.5	48.7±0.5	4.6±0.3	5.0±0.3	72.4±0.5	650W Max
EFD15	Horizontal	16.0Max	8.5±0.5	16.5±0.5	3.5±0.1	3.7±0.3	13.8±0.5	20W Max
EFD20		21.0Max	10.5±0.5	20.5±0.5	4.0±0.1	4.0±0.3	17.0±0.3	25W Max
EFD25		26.0Max	13.5±0.5	26.2±0.5	4.2±0.1	5.0±0.3	22.5±0.5	45W Max
EFD30		32.0Max	15.0±0.5	31.5±0.5	3.5±0.3	5.0±0.3	28.0±0.5	100W Max
EFD40		41.5Max	22.0±0.5	46.5±0.5	4.0±0.3	5.0±0.3	35.0±0.5	350W Max
EFD50		52.0Max	13.0±0.5	48.7±0.5	2.5±0.3	5.0±0.3	72.2±0.5	550W Max
