High Frequency Shipping Using Power Transformer
Product Details:
| Place of Origin: |
CHINA |
| Brand Name: |
IKP |
| Certification: |
CE/UL/REACH/ROHS |
| Model Number: |
IKP-EE65-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1000 |
| Price: |
0.95-1.00 |
| Packaging Details: |
Carton |
| Delivery Time: |
10-15 days |
| Payment Terms: |
L/C, T/T |
| Supply Ability: |
100,000/week |
Contact Now
Detailed Product Description
Basic Info.
Core
Core-type Transformer
Cooling Method
Oil-immersed Type Transformer
Winding Type
Multi-winding Transformer
Certification
ISO9001-2000, ISO9001
Frequency Characteristics
High Frequency
Specification
RoHS/SGS/UL/ISO9001
Production Capacity
5000000 Pics/Year
Product Description
Features:
1. Operating Frequency: 50~200KHz
2. Low-cost, all models mainly used in less demanding fields on the electromagnetic shielding power field.
3. Power frequency because of work, safety regulations and other requirements of the different temperature level will change.
Specifications (Unit: mm):
Note: The above are common skeleton styles; we accept customer requirements ODM or OEM. Welcome your design drawings or samples.
Electrical performance:
1. Operating frequency: 20kHz-500KHz
2. Output power: 30 to 80 W
3. Operating temperature:-40 ºCto +125 ºC
4. Storage temperature:-25 ºCto +85 ºC
Applications:
Household appliances, switching power supplies, communications equipments, medical equipments, production equipments, CCTV, computers, lighting equipments.
Kindly Reminder:
1. About the SAMPLES. Please provide specific specifications or sample material, we will evaluate your products, design and produce samples.
2. About PRICE. Transformers are custom products, due to the different materials and design, even if the same model, the price is not the same. The price also depends on the complexity of the parameters and the amount of orders.
3. About SHIPPING. Samples in 3-5 days; mass production in 7-15 days.
5. Packaging, logistics, according to the specific requirements of the purchase and sale contracts.
6. Contact us now for more details:
| PART NO. |
PINS |
Dimension(mm) |
| A |
B |
C+/-0.5 |
D+/-0.5 |
E+/-0.5 |
F |
TYPE |
| EE-8.3 |
6 |
8 |
8 |
6 |
4 |
2.5 |
8.3 |
V |
| EE-10 |
8 |
11.5 |
10.2 |
8 |
4 |
2.5 |
10.2 |
V |
| EE-13 |
10 |
12 |
12.5 |
8.5 |
4 |
2.5 |
13 |
V |
| EE16-1 |
6 |
14.8 |
13.3 |
9 |
4 |
3 |
16 |
V |
| EE-16-2 |
10 |
15.4 |
13 |
10.5 |
4 |
3.2 |
17.1 |
V |
| EE-16 |
10 |
28.5 |
16 |
12.3 |
4 |
4.3 |
21.9 |
V |
| EE-19-1 |
8 |
17.6 |
16 |
10 |
4 |
5 |
19 |
V |
| EE-19-2 |
10 |
17.2 |
16.2 |
13 |
4 |
3.9 |
20 |
V |
| EEL-19 |
10 |
31.5 |
16 |
10.5 |
4 |
4 |
21.1 |
V |
| EEL-19-1 |
10 |
15.6 |
30 |
24.1 |
4 |
3.5 |
21 |
H |
| EE-25-1 |
6 |
20 |
18.2 |
12.5 |
4 |
6.3 |
25.2 |
V |
| EE-25-2 |
8 |
21.7 |
17.5 |
12.6 |
4 |
5 |
25.2 |
H |
| EE-25-3 |
10 |
22.2 |
25 |
15.4 |
4 |
5 |
26.1 |
H |
| EEL-25 |
8 |
35.3 |
17.5 |
12.5 |
4 |
5 |
25.2 |
V |
| EE-30 |
10 |
21 |
29.2 |
25.2 |
4 |
5 |
30 |
H |
| EE-40 |
14 |
27.6 |
30.5 |
25.8 |
4 |
5 |
40 |
H |
| EE-42/15-1 |
12 |
33.8 |
44 |
35.5 |
4 |
5 |
42 |
H |
| EE-42/15-2 |
16 |
41.3 |
48 |
37.7 |
4 |
5 |
42 |
H |
| EE-42/15-3 |
18 |
48.7 |
32 |
27.5 |
4 |
5 |
45.1 |
V |
| EE-42/20-1 |
12 |
45 |
39.8 |
32.5 |
4 |
5 |
42 |
V |
| EE-42/20-2 |
16 |
44.2 |
50 |
37.8 |
4 |
5 |
42.2 |
H |
| EE-42/20-3 |
18 |
44.1 |
37 |
27.3 |
4 |
5 |
45.3 |
V |
| EE-55 |
20 |
50 |
50 |
45.5 |
4 |
5 |
55 |
H |
| EE-65 |
16 |
55.2 |
51.8 |
45 |
4 |
5 |
65 |
H |
| H :HORIZONTAL V:VERTICAL |
