High Frequency Filter Common Mode Inductor with RoHS, UL
Product Details:
| Place of Origin: |
CHINA |
| Brand Name: |
IKP |
| Certification: |
CE/UL/REACH/ROHS |
| Model Number: |
IKP-UU16 |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1000 |
| Price: |
0.09-0.15 |
| Packaging Details: |
Carton |
| Delivery Time: |
10-15 days |
| Payment Terms: |
L/C, T/T |
| Supply Ability: |
100,000/week |
Contact Now
Detailed Product Description
Basic Info.
Working Frequency
High Frequency
Structure of Winding
Multilayer Coil
Nature of Operation
Filter Inductor
Structure of Magnetizer
Ferrite Coil
Range of Application
Smoothing
Inductor Value
Variable Inductor
Production Capacity
5000000PCS/Year
Product Description
Model NO.: IKP-UU16
Operating Frequency: 20kHz-500KHz
Operating Temperature: -40
ºC to +125
ºC
Storage Temperature: -25
ºC to +85
ºC Working Frequency: High Frequ ency
Features
1. Small size
2. Easy to round
3. Low price
4. High reliability
5. Meeting UL, VDE, CSA requirements
6. Windings balanced within 1%
7. Customized specifications are welcome
8. Small, medium and high quantity is available.
Application
1. Common mode filter inductor
2. Driver transformer
3. Current Transformer
Electrical Specifications
| Model |
Mounting Style |
Length |
Width |
Height |
Pin Distance |
Row Distance |
Pin Diameter |
| UU9.8-01 |
Vertical |
17.0 |
12.0 |
17.0 |
2 |
7.0 |
8.0 |
Φ0.6 |
| UU9.8-02 |
Vertical |
17.0 |
16.0 |
13.0 |
2 |
7.0 |
8.0 |
Φ0.6 |
| UU10.5-01 |
Vertical |
19.0 |
17.5 |
22.0 |
2 |
10.0 |
13.0 |
Φ0.7 |
| UU10.5-02 |
Vertical |
19.0 |
19.0 |
17.0 |
2 |
10.0 |
13.0 |
Φ0.7 |
| UU15.7-01 |
Vertical |
23.0 |
19.0 |
26.5 |
2 |
10.0 |
13.0 |
Φ0.7 |
| UU15.7-02 |
Vertical |
23.0 |
25.0 |
23.0 |
2 |
10.0 |
13.0 |
Φ0.7 |
| UU16-01 |
Vertical |
23.0 |
19.0 |
26.5 |
2 |
10.0 |
13.0 |
Φ0.7 |
| UU16-02 |
Vertical |
23.0 |
25.0 |
23.0 |
2 |
10.0 |
13.0 |
Φ0.7 |
We can design and manufacture customized part with specific requirement.
