Common Mode Power Inductor (T22X14X13)

Common Mode Power Inductor (T22X14X13)

    • Common Mode Power Inductor (T22X14X13)
    • Common Mode Power Inductor (T22X14X13)
    • Common Mode Power Inductor (T22X14X13)
    • Common Mode Power Inductor (T22X14X13)
    • Common Mode Power Inductor (T22X14X13)
    • Common Mode Power Inductor (T22X14X13)
  • Common Mode Power Inductor (T22X14X13)

    Product Details:

    Place of Origin: CHINA
    Brand Name: IKP
    Certification: CE/UL/REACH/ROHS
    Model Number: IKP-T22x14x13

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000
    Price: 0.09-0.3
    Packaging Details: Carton
    Delivery Time: 10-15 days
    Payment Terms: L/C, T/T
    Supply Ability: 100,000/week
    Contact Now
    Detailed Product Description

    Basic Info.

    Model NO.
    IKP-T22x14x13
    Working Frequency
    High Frequency
    Structure of Winding
    Multilayer Coil
    Nature of Operation
    Choke Coil
    Structure of Magnetizer
    Ferrite Coil
    Range of Application
    Power Measurement
    Packaging Form
    Power Coils
    Brand
    OEM
    Inductor Value
    Variable Inductor
    Core Material
    Fe-Ni
    Used in Various Power Supplies
    Customized Designs Are Accepted
    Transport Package
    Carton/Pallet
    Specification
    Rohs, ISO9001
    Trademark
    IKP
    Origin
    Hefei, Anhui
    HS Code
    85045000
    Production Capacity
    5, 000 PCS/Week

    Product Description


    Common Mode Power Inductor (T22X14X13)
    Highest common mode impedance over the widest frequency range
    RoHS Directive-compliant
    PVC insulation shell
    Tin-silver over copper terminations
    High saturation flux density
    Less flux leakage and beat
    High effective insertion loss and excellent noise suppression
    Precise inductance
    High current, horizontal or vertical mount
    Operating temperature: -55 to 105°C
    Wide frequency range, large adjustable range for permeability (μ0) from 50,000-160,000
    Housing and tubes are available
    Customized specifications are accepted
    Applications: switching power output and smoothing circuits
    Used as choke coil for high frequency SMPs
    Countermeasure against spike ripples
    EMI/RFI filters
    DC/DC converters
    IP and OP devices
    Power inverter
    Part Number L@0Amps D.C.
    (MH)±20%
    MaxRDC.() Suggested Rated
    Current (Amps)
    ACL2929-0.2MH 0.20 .005 5.5
    ACL2929-0.8MH 0.80 .006 5.5
    ACL2929-1.8MH 1.80
    2.45
    .008 5.5
    ACL2929-3.2MH 3.20 .010 5.5
    ACL2929-5.0MH 5.00 .012 5.0
    ACL2929-7.2MH 7.20 .014 5.0
    ACL2929-9.8MH 9.80 .016 5.0
    ACL2929-12.8MH 12.80 .020 5.0
    ACL2929-16.2MH 16.20 .024 5.0
    ACL2929-20.0MH 20.00 .028 5.0
    ACL2929-24.2MH 24.20 .032 5.0
    ACL2929-28.8MH 28.80 .034 5.0
    ACL2929-33.8MH 33.80 .038 5.0
    ACL2929-39.2MH 39.20 .046 5.0
    ACL2929-45.0MH 45.00 .056 4.5
    ACL2929-51.2MH 51.20 .062 4.5
    ACL2929-57.8MH 57.80 .090 3.5
    ACL2929-64.8MH 64.80 .100 3.5
    ACL2929-57.0MH 57.00 .120 3.5
    ACL2929-80.0MH 80.00 .180 2.0
    Common Mode Power Inductor (T22X14X13)Common Mode Power Inductor (T22X14X13)Common Mode Power Inductor (T22X14X13)Common Mode Power Inductor (T22X14X13)Common Mode Power Inductor (T22X14X13)
