4 Pin Common Mode Drum Inductor

Key Specifications/Special Features:
-Operating temperature range:-25°C~+110°C with rated current
-Storage temperature range:-25°C~+110°C
-Large permissible D.C. current and low D.C. resistance
-PVC Sleeve protects the winding
-Tolerance of inductance:
3.30μH~39.0μH :±20% (M)
47.0μH ~560μH:±10% (K)
-Shielded SMD power chip inductor
-Magnetic shielded surface mount inductor with high-current rating
-Low profile and shielded very effective in space-conscious applications
-Low-resistant to deep power loss (minimum)
-Operating temperatures: -20 to 85°C (contain heating coil)
-Appearance inspection: no external defect by visual inspection
-Estimated order quantity
-Low DC resistance and large permissible DC current with high reliability
-Magnetic shielded products are available for each series for consideration against radiation
-High saturation magnetic-flux density and high efficiency
-Open Magnetic circuit construction
-Low cost and high reliability
-Small, medium and large quantities available




Applications:
-For smoothing circuit of DC-DC converter, as choke coil or chopper coil
-Suitable for use in power lines of camcorder, LCD set, OA equipment, notebook computer, PDA, -and small size communication equipment
-Notebook
-Inkjet printer
-Copying machine
-ADSL modem
-Cellular phone
-Display monitor
-Video tape recorder
-Video camera
-Color TV
-Lighting and car electronics

Reasons of our top-quality components help your business succeed:
-22 years of experience customizing and power transformers and inductors
-Your professional and reliable partner for various electronics
- Over 1000 buyers value our products
-20000m2 factory with 21 production lines and 800 employees
- 5 million units annual capacity

Browse our online showroom, and contact us with your OEM/ODM specifications. Our operators are waiting your calls and E-mail.
