| Place of Origin: | China |
| Brand Name: | IKP |
| Model Number: | IKP-LF-CMC Series |
| Minimum Order Quantity: | 1000 |
|---|---|
| Price: | 5.33USD |
| Packaging Details: | CARTON |
| Delivery Time: | 5-15 DAYS |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 20000PCS/DAY |
FEATURES:
Winding directly to the closed magnetic path core
Use the flat wire, improving the space factor
Small size, high current
Better heat dissipation
Single phase winding, thereby dramatically reduce stray capacitance
Achieve a high inductance in both common mode and normal mode
Achieve a high magnetic saturation characteristics
No layer-short, higher quality
EMI effect is excellent
Alternative products: UU10.5, UU16
Standard: CISPR22 Class B
Raw materials imported from Japan
Achieve TDK standards
Automatic machine winding, neatly arranged, high capacity
High insulation strength, improve power supply life
Preferred supplier aerospace, military, medical and electronics industries
APPLICATION:
Low Frequency AC Reactor, Solar Power System, Power Conditioning System,Wind Power System, Automatic Drive Machine, Induction Heater, Welding Machine, Paper Industries, RFI Suppression Choke, DC/DC converters, IP and OP devices.
Note:
We can design and manufacture customized part with specific requirement
| Part NO. | Inductance | Inductance Difference (max) |
DC resistance (max) |
Rated Current (max) |
Dimensions (ΦD) |
| T6030-752-5 | 7.5mH | 150μH | 0.1Ω | 5A | 0.9mm |
| T6030-162-10 | 1.6mH | 100μH | 0.02Ω | 10A | 1.3mm |
| T6030-102-14 | 1.0mH | 75μH | 0.02Ω | 14A | 1.5mm |
| T6035-201-30 | 0.2mH | 10μH | 3Ω | 30A | 2.6mm |
| T6035-501-25 | 0.5mH | 15μH | 5Ω | 25A | 2.3mm |
| T6035-102-20 | 1.0mH | 20μH | 8Ω | 20A | 2.0mm |
| T6035-162-15 | 1.6mH | 30μH | 12Ω | 15A | 1.8mm |
| T3524-302-3 | 3mH | 150μH | 100Ω | 3A | 0.8mm |
| T3524-502-3 | 5mH | 200μH | 130Ω | 3A | 0.8mm |
| T3524-102-5 | 1mH | 50μH | 50Ω | 5A | 1.0mm |
| T3524-202-5 | 2mH | 150μH | 60Ω | 5A | 1.0mm |
| T4333-502-5 | 5mH | 200μH | 55Ω | 5A | 1.1mm |
| T4333-302-7 | 3mH | 250μH | 35Ω | 7A | 1.3mm |
| T4333-102-10 | 1mH | 50μH | 15Ω | 10A | 1.5mm |
| T4333-501-15 | 0.5mH | 30μH | 8Ω | 15A | 1.8mm |
| T5228-102-5 | 1mH | 50μH | 45Ω | 5A | 1.0mm |
| T5228-502-5 | 5mH | 200μH | 95Ω | 5A | 1.0mm |
| T5228-302-8 | 3mH | 150μH | 40Ω | 8A | 1.2mm |
| T5228-102-10 | 1mH | 50μH | 20Ω | 10A | 1.3mm |
| T5228-202-10 | 2mH | 80μH | 25Ω | 10A | 1.5mm |
| T6332-202-15 | 2mH | 80μH | 20Ω | 15A | 2.0mm |
| T6332-152-18 | 1.5mH | 50μH | 15Ω | 18A | 2.1mm |
| T6332-102-20 | 1mH | 50μH | 8Ω | 20A | 2.3mm |
| T6332-501-25 | 0.5mH | 30μH | 6Ω | 25A | 2.5mm |
| T6340-302-10 | 3mH | 150μH | 35Ω | 10A | 1.5mm |
| T6340-202-15 | 2mH | 120μH | 25Ω | 15A | 1.8mm |
| T6340-102-20 | 1mH | 50μH | 10Ω | 20A | 2.3mm |
| T6340-102-25 | 1mH | 50μH | 8Ω | 25A | 2.4mm |
