80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System

80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System

    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
    • 80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System

    Product Details:

    Place of Origin: CHINA
    Brand Name: IKP
    Certification: CE/UL/REACH/ROHS
    Model Number: Toroidal Transformer

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000
    Price: 3.00-20.00
    Packaging Details: Carton
    Delivery Time: 10-15 days
    Payment Terms: L/C, T/T
    Supply Ability: 100,000/week
    Contact Now
    Detailed Product Description

    Specifications:

    • Power range:60VA to 150VA

    • Input / Output: Customized

    • Work Circle: Customized, such as ED 80%

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome

    Rated Power

    (VA)

    Frequency

    (Hz)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		 Approval
    60 50/60 98*35 0.9 48 UL/CE/RoHS/CQC
    80 50/60 98*45 1.25 53 UL/CE/RoHS/CQC
    105 50/60 98*45 1.30 54 UL/CE/RoHS/CQC
    120 50/60 98*45 1.35 55 UL/CE/RoHS/CQC
    150 50/60 98*55 1.60 56 UL/CE/RoHS/CQC

    ◆We can design and manufacture customized part with specific requirement

    80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System◆We can design and manufacture customized part with specific requirement



    80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System80VA Rated Power 50/60Hz Frequency Toroidal Transformer for Door Control System
