| Place of Origin: | CHINA |
| Brand Name: | IKP |
| Certification: | CE/UL/REACH/ROHS |
| Model Number: | C46 |
| Minimum Order Quantity: | 1000 |
|---|---|
| Price: | 0.02-0.2 |
| Packaging Details: | Carton |
| Delivery Time: | 10-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100,000/week |
High Magnetic Permeability: The C-type Mn-Zn high permeability magnetic strip exhibits a high magnetic permeability, which is beneficial for enhancing the efficiency and performance of devices. Under high-frequency and high flux density operating conditions, its permeability remains relatively high, thereby reducing energy losses and improving the operational efficiency of the equipment.
Low Energy Consumption: This material has a low energy consumption, which helps to reduce the operating costs of devices. In electronic equipment, low energy consumption means a longer service life and lower heat generation, thereby enhancing the stability and reliability of the equipment.
Good Stability: The C-type Mn-Zn high permeability magnetic strip has excellent temperature stability and time stability, maintaining stable magnetic properties over a wide temperature range.
Good Anti-interference Ability: Due to its high magnetic permeability, the C-type Mn-Zn high permeability magnetic strip has a strong shielding effect against external magnetic fields, effectively preventing external magnetic fields from interfering with the circuit. This is of great significance for improving the anti-interference ability and electromagnetic compatibility of electronic devices.
Communication Field: In communication devices such as mobile phones and base stations, the C-type Mn-Zn high permeability magnetic strip is widely used in components like filter inductors and antennas to improve the quality and stability of signal transmission.
Power Field: In devices such as switch mode power supply transformers, LCD and PDP power converters, and external power adapters, the C-type Mn-Zn high permeability magnetic strip plays an important role. It can reduce power loss, improve the conversion efficiency and stability of power supplies.
Anti-Electromagnetic Interference Field: Due to its good anti-interference ability, the C-type Mn-Zn high permeability magnetic strip is often used to make anti-Electromagnetic interference filters, inductors, and other components to suppress high-frequency noise and Electromagnetic interference.
Other Fields: In addition to the above fields, the C-type Mn-Zn high permeability magnetic strip is also widely used in lighting equipment, medical equipment, automotive electronics, and other fields. For example, in lighting equipment, it can be used to make electronic ballasts; in automotive electronics, it can be used to make sensors and actuators.
Fig.1 Fig.2
| Specification | Figure | Dimension(mm) | Compression strength | Q-value | Inductor coefficient AL(nH/N2) | Weight | |||
| A | B | C | D | (N) | Q | BP40 | (grams/pair) | ||
| C14×5×11 | 1 | 14.37±0.5 | / | 11±0.25 | 5±0.2 | ≥200 | / | / | 3.6 |
| C25.2×10.5×4.5 | 1 | 25.2±0.2 | / | 10.5+0.5/-0 | 4.5±0.1 | ≥200 | ≥1.35 | ≥400 | 6 |
| C46×4×11 | 1 | 38.6±0.4 | / | 11±0.3 | 4±0.2 | ≥160 | / | / | 7.9 |
| C64.8×30×8 | 2 | 64.8±0.5 | 30±1 | 8±0.2 | 7±0.2 | / | / | / | 26 |
Note:
The test conditions for the AL value are: 1KHz, 0.3V, and 10Ts.
The above are the standard specifications of our company, and we can design according to the special requirements of customers.
