YBD11 Type Mine Geophysical Prospecting Electric Instruments

Features:

1. Realize two-dimensional or three-dimensional electric method exploration of various electric fields on the ground, such as resistivity method exploration, natural potential method exploration, charging method exploration, and IP method exploration;

2. Integrated host built-in ARM, network communication, internal power supply and external intrinsically safe power supply and other functional modules;

3. Remote monitoring through the mine's Internet of Things;

4. The integrated host can connect N acquisition base stations through distributed and centralized two electric system to form the parallel electric field exploration and monitoring of 16n channel excitation and 16n channel reception. The user can arbitrarily select the number of electrode tracks according to the requirements;

5. Real-time display of current and voltage signal waveforms, apparent resistivity profiles, and apparent polarizability profiles;

6. One-click mapping mode, the operation is more simplified;

7. Storage capacity up to 32GB;

8. Dual mode electrode with excitation and reception separation.

Application:

Using the all-electric field observation technique, the natural electric field, the primary electric field potential, and the secondary electric field potential data of all the measuring points are simultaneously acquired. This greatly improves the efficiency and accuracy of data acquisition by electrical methods. The product is widely used in mines, tunnels, subways, water conservancy, urban public safety, electric power and other underground engineering hidden danger detection and monitoring and resource exploration.

Parameters:
