| Place of Origin: | CHINA |
| Brand Name: | IKP |
| Certification: | CE/UL/REACH/ROHS |
| Model Number: | Toroidal Transformer |
| Minimum Order Quantity: | 1000 |
|---|---|
| Price: | 3.00-20.00 |
| Packaging Details: | Carton |
| Delivery Time: | 10-15 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100,000/week |
Specifications:
• Power range:0VA to 5000VA
• Input / Output: Customized
• Insulation Class: UL class B, F, H, N (optional)
• Isolation: 4KV (Hi-pot)
• Easy to change diameter and height of the core
• Customized specifications are welcome
|
Rated Power (VA) |
Outside Dimension D*H(mm) |
Weight (kg) |
Temp. Rise (℃) |
Approval |
| 50 | 80*37 | 0.71 | 45 | UL/CE/RoHS/CQC |
| 100 | 95*45 | 1.24 | 51 | UL/CE/RoHS/CQC |
| 200 | 112*52 | 2.04 | 52 | UL/CE/RoHS/CQC |
| 250 | 118*53 | 3.36 | 53 | UL/CE/RoHS/CQC |
| 500 | 140*65 | 4.20 | 55 | UL/CE/RoHS/CQC |
| 1000 | 170*75 | 7.20 | 58 | UL/CE/RoHS/CQC |
| 1500 | 180*85 | 9.75 | 60 | UL/CE/RoHS/CQC |
| 2000 | 185*105 | 12.00 | 62 | UL/CE/RoHS/CQC |
| 3000 | 200*120 | 16.60 | 64 | UL/CE/RoHS/CQC |
| 5000 | 230*135 | 24.00 | 65 | UL/CE/RoHS/CQC |
◆We can design and manufacture customized part with specific requirement
◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement
